Heavy Duty Industrial Semi Automatic Screen Printing Machine With Servo Motors For Flat Printing
Machine Introduction
This is a high-precision, high-efficiency servo contour screen printing machine, controlled by touch screen and PLC. It adopts servo control for vertical movement, left-right printing, print head, and worktable rotary positioning. Stable performance, high printing accuracy, and elegant appearance.
Key Features
- Touch screen HMI + PLC control system, durable, easy maintenance, powerful functions
- Full touch screen human-machine control, simple operation
- Automatic counter for printing quantity statistics
- Double-column lifting structure with servo motor control
- Adjustable left-right stroke with servo motor control
- Servo-controlled print head
- Servo-controlled worktable rotation
- Multiple printing cycle modes available for different processes:
- Semi-automatic single cycle: foot switch & inching mode
- Fully automatic continuous printing
- Constant pressure scraper device with digital pressure gauge for stable printing pressure
Technical Parameters
- Operation Mode: Selectable
- Start Method: Control panel / Foot switch
- Squeegee Pressure: Regulator with constant pressure control
- Vertical Drive: Servo motor
- Horizontal Drive: Servo motor
- Print Head: Servo control
- Worktable: Servo rotation control
- Left-Right Stroke: 1200 mm
- Vertical Stroke: 200 mm
- Max Screen Size: 900 * 1350 mm
- Printing Area: 700 * 1200 mm
- Machine Dimensions: L 1100 * W 1500 * H 1700 mm
About us
Dongguan Hao'an Printing Machinery Co., Ltd. is a professional manufacturer of automated printing equipment, established in 2016. Its products include silk screen printing machines, transfer printing machines, stamping machines, and peripheral equipment, which can meet printing requirements of various shapes and materials. It is widely used in various fields and industrys suchs as cosmetics, daily necessities, food, medical supplies, and automotive accessories. The machinery and equipment are exported to multiple countries and regions suchs as Europe, the United States, South Korea, the Middle East, South Africa, Mexico, etc., and are highly trusted by domestic and foreign customers.
We always adhere to the five core concepts of "efficiency, excellence, energy conservation, integrity, and win-win", and are committed to providing customers with suitable and excellent technical solutions. Haoan has a strong professional technology research and development team that can customize the most suitable machinery and equipment according to the different requirements of customers, and will continue to innovate to make products intelligent and efficient. The company not only provides excellent machinery and equipment, but also provides professional technical training and supporting services, truly achieving what customers want and reach.
FAQ
- Q. How long is the machine's warranty period? A.We offer a 2-year warranty and long-term service
- Q. What technical support services are provided after purchase? A.We provide on-site installation service and professional engineer training
- Q. How will you help us resolve after-sales repair issues if the machine malfunctions? A.In case of machine malfunction, we will provide video and email communication, and on-site service is available if necessary
- Q. What inks does the machine support? A.We use UV-based environmentally friendly inks, imported environmentally friendly inks
- Q.What certifications can you provide? A.We have ISO9001, SGS, and RoHS certifications
